General
Boat Type
Monohull
Hull Type
Fin Keel With Spade Rudder
Rigging Type
Cutter
Construction
Glass-Reinforced Plastic
First Built
2000
Builder
Bsi Marine Sweden A.B.
Designer
Bruce Farr
Technical Specifications
FARR 56 PILOT HOUSE
The FARR 56 PILOT HOUSE is a cutter with a fin keel with spade rudder, built by Bsi Marine Sweden A.b. to a design by Bruce Farr. First built in 2000, published specifications include length overall of 17.60 m (57.74 ft), beam of 5.06 m (16.60 ft), and hull speed of 9.49 knots.
2000
First Built
17.60 m
LOA
15.30 m
LWL
5.06 m
Beam
Buy FARR 56 PILOT HOUSE Sails
Mainsails from $2,870.98, custom-made for your boat
FARR 56 PILOT HOUSE Full Specifications
Dimensions
17.60 m
Length Overall
LWL
15.30 m
Max Draft
2.50 m
Beam
5.06 m
Hull Speed
9.49 kn
Fuel Capacity
1,136.00 l
Water Capacity
757.00 l
Displacement & Stability
Displacement
20,500.00 kg
Ballast
6,750.00 kg
Pounds Per Inch
1,350.59 kg
Comfort Ratio
31.59
Capsize Screening
1.87
Engine
Engine Make
Yanmar
Engine Model
4lha-Htp
Engine Type
Diesel
Horsepower
160
Sail & Rigging
I
22.36 m
J
6.74 m
P
19.61 m
E
6.93 m
Max Luff
21.60 m
Est. Forestay Length
23.35 m
Buy Sails For FARR 56 PILOT HOUSE
FARR 56 PILOT HOUSE Jib
FARR 56 PILOT HOUSE Genoa
FARR 56 PILOT HOUSE Foresail
FARR 56 PILOT HOUSE Mainsail
Mainsail pricing for the FARR 56 PILOT HOUSE is based on the rig dimensions for this model and your selected build and finish options.
Short Batten Mainsail Dimensions
Sail Area76.10 m²
Sailcloth Weight9.50 oz
Mainsail Area Triangle67.95 m²
Upwind Area 100143.30 m²
Common Questions
After you complete your purchase this is what will happen:
- We prepare your Build Details — the measurements and sail construction — and send them to you to confirm.
- Once confirmed, the information goes to our sail designer, who creates a detailed design plan.
- The design is sent to you for review and approval.
- Once approved, we proceed with making the sail.
Pricing for FARR 56 PILOT HOUSE sails is calculated from the stored dimensions for this model, the selected sail type, the chosen build, and any relevant optional extras. Final quotations should still be checked against the actual rig, hardware, and fit of the boat before production.
Cross-cut construction is typically the more straightforward cruising option, with strong day-to-day durability and simpler panel layout. Radial-cut construction uses load-aligned paneling where available, which generally improves shape retention and performance.
Yes. Optional extras are tied to the selected sail family and sail type, so only relevant options are shown in the configurator. Hardware, reefs, UV treatments, bags, ropes, and reinforcement packages appear only where they apply.
Published specifications are the starting point, not the final production sign-off. If your spar, furler, hardware, or previous sail measurements differ, use the quotation flow so the specification can be reviewed before an order is confirmed.
